Level Two Interface
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 8-30
ID012310 Non-Confidential, Unrestricted Access
8.5.27 Cacheable Write-Through or Noncacheable STM4
Table 8-52 shows the values of AWADDRRW, AWBURSTRW, AWSIZERW, and
AWLENRW for STM4s to words 0 to 4 over the Data Read/Write Interface.
An STM4 to words 5 to 7 is split into two operations as shown in Table 8-53.
8.5.28 Cacheable Write-Through or Noncacheable STM5
Table 8-54 shows the values of AWADDRRW, AWBURSTRW, AWSIZERW, and
AWLENRW for STM5s to words 0 to 3 over the Data Read/Write Interface.
An STM5 to words 4 to 7 is split into two operations as shown in Table 8-55.
Table 8-52 Cacheable Write-Through or Noncacheable STM4 to word 0, 1, 2, 3, or 4
Address[4:0]
AWADDRR
W
AWBURSTR
W
AWSIZERW AWLENRW First WSTRBRW
0x00 , word 0 0x00 Incr 64-bit 2 data transfers b1111 1111
0x04 , word 1 0x04 Incr 32-bit 4 data transfers b11110000
0x08 , word 2 0x08 Incr 64-bit 2 data transfers b11111111
0x0C , word 3 0x0C Incr 32-bit 4 data transfers b11110000
0x10 , word 4 0x10 Incr 64-bit 2 data transfers b11111111
Table 8-53 Cacheable Write-Through or Noncacheable STM4 to word 5, 6, or 7
Address[4:0] Operations
0x14 , word 5 STM3 to 0x14 + STR to 0x00
0x18
, word 6 STM2 to 0x18 + STM2 to 0x00
0x1C
, word 7 STR to 0x1C + STM3 to 0x00
Table 8-54 Cacheable Write-Through or Noncacheable STM5 to word 0, 1, 2, or 3
Address[4:0]
AWADDRR
W
AWBURSTR
W
AWSIZERW AWLENRW First WSTRBRW
0x00 , word 0 0x00 Incr 32-bit 5 data transfers b0000 1111
0x04 , word 1 0x04 Incr 32-bit 5 data transfers b1111 0000
0x08 , word 2 0x08 Incr 32-bit 5 data transfers b0000 1111
0x0C , word 3 0x0C Incr 32-bit 5 data transfers b1111 0000
Table 8-55 Cacheable Write-Through or Noncacheable STM5 to word 4, 5, 6, or 7
Address[4:0] Operations
0x10 , word 4 STM4 to 0x10 + STR to 0x00
