Cycle Timings and Interlock Behavior

ID012310 Non-Confidential, Unrestricted Access

16.16 SVC, SMC, BKPT, Undefined, and Prefetch Aborted instructions

This section describes the cycle timing behavior for SVC, SMC, Undefined Instruction, BKPT

and Prefetch Abort.

In all cases, the exception is taken in the WBex stage of the pipeline. SVC, SMC, and most

Undefined instructions that fail their condition codes take one cycle. A small number of

undefined instructions that fail their condition codes take two cycles. Table 16-23 lists the SVC,

SMC, BKPT, undefined, prefetch aborted instructions cycle timing behavior.

Table 16-23 SVC, BKPT, undefined, prefetch aborted instructions cycle timing behavior

Instruction

Cycle

SVC 8

SMC 8

BKPT 8

Prefetch Abort 8

Undefined Instruction 8
