Cycle Timings and Interlock Behavior

ID012310 Non-Confidential, Unrestricted Access

16.4 QADD, QDADD, QSUB, and QDSUB instructions

This section describes the cycle timing behavior for the QADD, QDADD, QSUB, and QDSUB

instructions.

These instructions perform saturating arithmetic. Their result is produced during the Sat stage,

consequently they have a result latency of two. The QDADD and QDSUB instructions must

double and saturate the register

<Rn>

before the addition. This operation occurs in the Sh stage

of the pipeline, consequently this register is an Early Reg.

Table 16-6 lists the cycle timing behavior for QADD, QDADD, QSUB, and QDSUB

instructions.

Table 16-6 QADD, QDADD, QSUB, and QDSUB instruction cycle timing behavior

Instructions

Cycle

Early Reg Result latency

QADD, QSUB 1 - 2

QDADD, QDSUB 1

<Rn>
