ARM ARM1176JZF-S - Table B-2 CP15 C15 Features Common to ARM1136 JF-S and ARM1176 JZF-S Processors

To Next Page

To Previous Page

Summary of ARM1136JF-S and ARM1176JZF-S Processor Differences

ID012310 Non-Confidential, Unrestricted Access

Table B-2 lists the CP15 c15 registers and operations common to both ARM1176JZF-S and

ARM1136JF-S processors.

Table B-2 CP15 c15 features common to ARM1136JF-S and ARM1176JZF-S processors

CRn Opcode_1 CRm Opcode_2 Register Function

c15 0 c2 4 Peripheral Memory Remap

c12 0 Performance Monitor Control

1 Cycle Counter

2 Count Register 0

3 Count Register 1

3 c8 0 Instruction Cache Master Valid

c12 0 Data Cache Master Valid

a. Only applies for Lockdown entries.

c4 2 TLB Lockdown Index

c5 2 TLB Lockdown VA

c6 2 TLB Lockdown PA

c7 2 TLB Lockdown Attributes
