System Control Coprocessor
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 3-30
ID012310 Non-Confidential, Unrestricted Access
• CRn set to c0
• CRm set to c1
• Opcode_2 set to 2.
For example:
MRC p15, 0, <Rd>, c0, c1, 2 ;Read Debug Feature Register 0
c0, Auxiliary Feature Register 0
The purpose of the Auxiliary Feature Register 0 is to provide additional information about the
features of the processor.
The Auxiliary Feature Register 0 is:
•in CP15 c0
• a 32-bit read-only register common to the Secure and Non-secure worlds
• accessible in privileged modes only.
Table 3-18 lists how the bit values correspond with the Auxiliary Feature Register 0 functions.
The contents of the Auxiliary Feature Register 0 [31:16] are Reserved. The contents of the
Auxiliary Feature Register 0 [15:0] are Implementation Defined. In the ARM1176JZF-S
processor, the Auxiliary Feature Register 0 reads as
0x00000000
.
Table 3-19 lists the results of attempted access for each mode.
To use the Auxiliary Feature Register 0 read CP15 with:
• Opcode_1 set to 0
• CRn set to c0
• CRm set to c1
• Opcode_2 set to 3.
For example:
MRC p15, 0, <Rd>, c0, c1, 3 ;Read Auxiliary Feature Register 0.
Table 3-18 Auxiliary Feature Register 0 bit functions
Bits Field name Function
[31:16] - Reserved. RAZ.
[15:12] - Implementation Defined.
[11:8] - Implementation Defined.
[7:4] - Implementation Defined.
[3:0] - Implementation Defined.
Table 3-19 Results of access to the Auxiliary Feature Register 0
Secure Privileged Non-secure Privileged
User
Read Write Read Write
Data Undefined exception Data Undefined exception Undefined exception
