The VFP Register File

ID012310 Non-Confidential, Unrestricted Access

Table 19-4 VFP11 MRRC instructions

Instruction Operation Description

FMRRD Rd = Dm[31:0]

Rn = Dm[63:32]

Move from lower and upper halves of VFP11 double-precision register Dm to

ARM11 registers Rd and Rn.

FMRRS Rd = Sm

Rn = S(m + 1)

Move from single-precision VFP11 registers Sm and S(m + 1) to ARM11 registers

Rd and Rn.
