Cycle Timings and Interlock Behavior
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 16-19
ID012310 Non-Confidential, Unrestricted Access
16.11 Load and Store Double instructions
This section describes the cycle timing behavior for the LDRD and STRD instructions
The LDRD and STRD instructions:
Are two-cycle issue if either a negative register offset or a shift other than LSL #2 is used.
Only the offset register is an Early Reg.
Are single-cycle issue if either a constant offset is used or if a register offset with no shift,
or shift by 2 is used. Both the base and any offset register are Early Regs.
Take only one memory cycle if the address is doubleword aligned.
Take two memory cycles if the address is not doubleword aligned.
The updated base register has a result latency of one. For back-to-back load/store instructions
with base write back, the updated base is available to the following load/store instruction with a
result latency of 0.
To prevent instructions after a STRD from writing to a register before it has stored that register,
the STRD registers have a lock latency that determines how many cycles it is before a
subsequent instruction that writes to that register can start.
Table 16-16 lists the cycle timing behavior for LDRD and STRD instructions.
Table 16-17 lists the explanation of
<addr_md_1cycle>
and
<addr_md_2cycle>
that Table 16-16
uses.
Table 16-16 Load and Store Double instructions cycle timing behavior
Example instruction
Cycle
s
Memory cycles
Result latency
(LDRD)
Register lock latency
(STRD)
Address is double-word aligned
LDRD R1, <addr_md_1cycle>
a
11 3/3 1,2
LDRD R1, <addr_md_2cycle>
a
22 4/4 2,3
Address not double-word aligned
LDRD R1, <addr_md_1cycle>
a
12 3/4 1,2
LDRD R1, <addr_md_2cycle>
a
23 4/5 2,3
a. Table 16-17 for an explanation of
<addr_md_1cycle>
and
<addr_md_2cycle>
.
Table 16-17 <addr_md_1cycle> and <addr_md_2cycle> LDRD example instruction explanation
Example instruction Early Reg Comment
<addr_md_1cycle>
