System Control Coprocessor
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 3-124
ID012310 Non-Confidential, Unrestricted Access
The Interrupt Status Register is:
• in CP15 c12
• a 32-bit read-only register common to Secure and Non-secure worlds
• accessible in privileged modes only.
Figure 3-67 shows the arrangement of bits in the register.
Figure 3-67 Interrupt Status Register format
Table 3-125 lists how the bit values correspond with the Interrupt Status Register functions.
Note
• The F and I bits directly reflect the state of the nFIQ and nIRQ pins respectively, but are
the inverse state.
• The A bit is set when an external abort occurs and automatically clears when the abort is
taken.
Table 3-126 lists the results of attempted access for each mode.
The A, I, and F bits map to the same format as the CPSR so that you can use the same mask for
these bits.
SBZ
31 98765 0
A I F SBZ
Table 3-125 Interrupt Status Register bit functions
Bits Field name
Function
a
a. The reset values depend on external signals.
[31:9] - SBZ.
[8] A Indicates when an external abort is pending:
0 = No abort, reset value
1 = Abort pending.
[7] I Indicates when an IRQ is pending:
0 = no IRQ, reset value
1 = IRQ pending.
[6] F Indicates when an FIQ is pending:
0 = no FIQ, reset value
1 = FIQ pending.
[5:0] - SBZ.
Table 3-126 Results of access to the Interrupt Status Register
Secure Privileged Non-secure Privileged
User
Read Write Read Write
Data Undefined exception Data Undefined exception Undefined exception
