Memory Management Unit

ID012310 Non-Confidential, Unrestricted Access

The debug control coprocessor CP14 also influences the MMU when in Debug state. Table 6-17

lists the registers that affect the MMU.

Table 6-17 CP14 register functions

Debug State MMU Control Register CP14 c11, Debug State MMU Control Register on page 13-23

Debug State Cache Control Register CP14 c10, Debug State Cache Control Register on page 13-23
