Unaligned and Mixed-endian Data Access Support
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 4-4
ID012310 Non-Confidential, Unrestricted Access
4.2.3 Legacy and ARMv6 configurations
Table 4-1 summarizes the unaligned access handling.
4.2.4 Legacy data access in ARMv6 (U=0)
The processor emulates earlier architecture unaligned accesses to memory as follows:
• If A bit is asserted alignment faults occur for:
Halfword access Address[0] is 1.
Word access Address[1:0] is not b00.
LDRD or STRD Address [2:0] is not b000.
Multiple access Address [1:0] is not b00.
• If alignment faults are enabled and the access is not aligned then the Data Abort vector is
entered with an Alignment Fault status code.
• If no alignment fault is enabled, that is, if bit 1 of CP15 Register c1, the A bit, is not set:
Byte access Memory interface uses full Address [31:0].
Halfword access Memory interface uses Address [31:1]. Address [0] asserted as 0.
Word access Memory interface uses Address [31:2]. Address [1:0] asserted as 0.
— ARM load data rotates the aligned read data and rotates this right by the byte-offset
denoted by Address [1:0], see the ARM Architecture Reference Manual.
— ARM and Thumb load-multiple accesses always treated as aligned. No rotation of
read data.
— ARM and Thumb store word and store multiple treated as aligned. No rotation of
write data.
— ARM load and store doubleword operations treated as 64-bit aligned.
For more information, see Operation of unaligned accesses on page 4-13.
4.2.5 Support for unaligned data access in ARMv6 (U=1)
The processor memory interfaces can generate unaligned low order byte address offsets only for
halfword and single word load and store operations, and byte accesses unless the A bit is set.
These accesses produce an alignment fault if the A bit is set, and for some of the cases that
ARMv6 unaligned data access restrictions on page 4-5 describes.
If alignment faults are enabled and the access is not aligned then the Data Abort vector is entered
with an Alignment Fault status code.
Table 4-1 Unaligned access handling
CP15 register
c1 U bit
CP15 register
c1 A bit
Unaligned access model
0 0 Legacy ARMv5. See Legacy data access in ARMv6 (U=0).
0 1 Legacy natural alignment check.
1 0 ARMv6 unaligned half/word access, else strict word alignment check.
1 1 ARMv6 strict half/word alignment check.
