Memory Management Unit

ID012310 Non-Confidential, Unrestricted Access

6.12.2 First-level descriptor

Using the first-level descriptor address, a request is made to external memory. This returns the

first-level descriptor. By examining bits [1:0] of the first-level descriptor, the access type is

indicated as Table 6-14 lists.

First-level translation fault

If bits [1:0] of the first-level descriptor are b00 or b11, a translation fault is generated. This

generates an abort to the processor, either a Prefetch Abort for the instruction side or a Data

Abort for the data side, see MMU fault checking on page 6-29.

If the first level descriptor describes a section or supersection when the Force AP bit is set and

the MMU is in ARMv6 mode, Access bit faults might be generated if AP[0]=0.

First-level page table address

If bits [1:0] of the first-level descriptor are b01, then a page table walk is required. Second-level

page table walk on page 6-47 describes this process.

First-level section base address

If bits [1:0] of the first-level descriptor are b10, a request to a section memory block has

occurred. Figure 6-11 on page 6-46 shows the translation process for a 1MB section using

ARMv6 format, AP bits disabled.

Table 6-14 Access types from first-level descriptor bit values

Bit values Access type

b00 Translation fault

b01 Page table base address

b10 Section base address

b11 Reserved, results in translation fault

ARM ARM1176JZF-S User Manual
