ID012310 Non-Confidential, Unrestricted Access

Appendix A

Signal Descriptions

This appendix lists and describes the processor signals. It contains the following sections:

• Global signals on page A-2

• Static configuration signals on page A-4

• TrustZone internal signals on page A-5

• Interrupt signals, including VIC interface on page A-6

• AXI interface signals on page A-7

• Coprocessor interface signals on page A-12

• Debug interface signals, including JTAG on page A-14

• ETM interface signals on page A-15

• Test signals on page A-16.

Note

The output signals that Table A-1 on page A-2 to Table A-14 on page A-16 list are set to 0 on reset

unless otherwise stated.
