Memory Management Unit
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 6-40
ID012310 Non-Confidential, Unrestricted Access
Bits [1:0] == b01
The entry points to a second-level page table, called a Coarse page table.
Figure 6-8 on page 6-40 shows the formats of the possible entries in the Coarse
page table.
Bits [1:0] == b10
The entry points to a either a 1MB Section of memory or a 16MB Supersection
of memory. Bit [18] of the descriptor selects between a Section and a
Supersection. For details of supersections see Supersections on page 6-6.
Note
You must repeat any Supersection description in 16 consecutive page table
locations, with the first description occurring on a 16-word boundary. For more
information see the ARM Architecture Reference Manual.
Bits [1:0] == b11
Reserved.
Figure 6-8 shows the format of an ARMv6 second-level descriptors.
Figure 6-8 ARMv6 second-level descriptor format
As shown in Figure 6-8, bits [1:0] of a second-level descriptor determine the type of the
descriptor:
Bits [1:0] == b00
Translation fault.
Bits [1:0] == b01
The entry points to a 64KB Large page in memory.
Note
You must repeat any Large page description in 16 consecutive page table
locations, with the first description occurring on a 16-word boundary. For more
information see the ARM Architecture Reference Manual.
Bits [1:0] == b1x
The entry points to a 4KB Extended small page in memory.
Bit [0] of the entry is the XN bit for the entry.
Figure 6-9 on page 6-41 shows an overview of the section, supersection, and page translation
process using ARMv6 descriptors.
n
G
S
X
N
S
A
P
X
TEX
B
1Large page base address
SBZ
AP C 0
X
N
Extended small page base address
n
G
A
P
X
TEX AP C B 1
Translation fault
Large page (64KB)
Extended small
page (4KB)
0Ignored
31 16 15 12 11 10 9 8 7 6 5 4 3 2 1 0
0
14
