A.9 Test signals

Table A-14 lists the test signals.

Table A-14 Test signals

Name Direction Description

SE Input Scan enable

RSTBYPASS Input Bypass of reset repeaters

MTESTON Input BIST enable

MBISTDIN[63:0] Input MBIST data in

MBISTADDR[12:0] Input MBIST address

MBISTCE[19:0] Input MBIST chip enable

MBISTWE[7:0] Input MBIST write enable

MBISTDOUT[63:0] Output MBIST data out

nVALIRQ Output Request for an interrupt

nVALFIQ Output Request for a fast interrupt

nVALRESET Output Request for a reset

VALEDBGRQ Output Request for an external debug request
