ARM ARM1176JZF-S User Manual

Introduction
ARM DDI 0301H Copyright © 2004-2009 ARM Limited. All rights reserved. 1-44
ID012310 Non-Confidential, Unrestricted Access
1.10.2 Thumb instruction set summary
Table 1-16 summarizes the Thumb instruction set.
LS Unsigned lower or same
GE Signed greater or equal
LT Signed less than
GT Signed greater than
LE Signed less than or equal
AL Always
Table 1-15 Condition codes (continued)
Suffix Description
Table 1-16 Thumb instruction set summary
Operation Assembler
Move Immediate, update flags
MOV <Rd>, #<immed_8>
LowReg to LowReg, update flags MOV <Rd>, <Rm>
HighReg to LowReg MOV <Rd>, <Rm>
LowReg to HighReg MOV <Rd>, <Rm>
HighReg to HighReg MOV <Rd>, <Rm>
Copy CPY <Rd>, <Rm>
Arithmetic Add ADD <Rd>, <Rn>, #<immed_3>
Add immediate ADD <Rd>, #<immed_8>
Add LowReg and LowReg, update flags ADD <Rd>, <Rn>, <Rm>
Add HighReg to LowReg ADD <Rd>, <Rm>
Add LowReg to HighReg ADD <Rd>, <Rm>
Add HighReg to HighReg ADD <Rd>, <Rm>
Add immediate to PC ADD <Rd>, PC, #<immed_8*4>
Add immediate to SP ADD <Rd>, SP, #<immed_8*4>
Add immediate to SP ADD SP, #<immed_7*4>
ADD SP, SP, #<immed_7*4>
Add with carry ADC <Rd>, <Rs>
Subtract immediate SUB <Rd>, <Rn>, #<immed_3>
Subtract immediate SUB <Rd>, #<immed_8>
Subtract SUB <Rd>, <Rn>, <Rm>
Subtract immediate from SP SUB SP, #<immed_7*4>
Subtract with carry SBC <Rd>, <Rm>
