Cycle Timings and Interlock Behavior

ID012310 Non-Confidential, Unrestricted Access

LDRD <Rd>, [<Rn>, #cns] (!) <Rn>

If an immediate offset, or a positive register offset with no

shift or shift LSL #2, then one-issue cycle.

LDRD <Rd>, [<Rn>, <Rm>] (!) <Rn>, <Rm>

LDRD <Rd>, [<Rn>, <Rm>, LSL #2] (!) <Rn>, <Rm>

LDRD <Rd>, [<Rn>], #cns <Rn>

LDRD <Rd>, [<Rn>], <Rm> <Rn>, <Rm>

LDRD <Rd>, [<Rn>], <Rm>, LSL #2 <Rn>, <Rm>

<addr_md_2cycle>

LDRD <Rd>, [<Rn>, -<Rm>] (!) <Rm>

If negative register offset, or shift other than LSL #2 then

two-issue cycles.

LDRD Rd, [<Rm>, -<Rm> <shf> <cns>] (!) <Rm>

LDRD <Rd>, [<Rn>], -<Rm> <Rm>

LDRD< Rd>, [Rn], -<Rm> <shf> <cns> <Rm>

Table 16-17 <addr_md_1cycle> and <addr_md_2cycle> LDRD example instruction explanation (continued)

Example instruction Early Reg Comment
