EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY ADF Section 522
REINSTALLATION
1. Secure the COVER SENSOR to the FIX PLATE R with the screw (M2 x 10 mm,
G-type, P-head). See Figure 4-214.
2. Secure the harnesses of the COVER SENSOR with the two clamps of the FIX
PLATE R.
3. Secure the three gears to the FIX PLATE R in the order given below. See Figure
4-213.
1. GEAR 40T 18T
2. GEAR 48T
3. GEAR 60T 18T
4. Secure the MOTOR FIX PLATE and the two LOCKING CABLE CLIPS to the
FIX PLATE with the three screws (M3 x 6 mm, S-type, A-head). See Figure
4-212.
5. Secure the grounding wire of the CABLE to the MOTOR FIX PLATE with the
screw (M3 x 6 mm, S-type, A-head). See Figure 4-212.
6. Attach the MOTOR. (p509)
7. Attach the ADF BASE ASSY. (p498)
8. Attach the ADF COVER C. (p496)
9. Attach the PAPER GUIDE ASSY. (p526)
10. Attach the ADF COVER R. (p492)
11. Attach the ADF Unit. (p481)
12. Install the Scanner. (p306)
A D J U S T M E N T
R E Q U I R E D
Be sure to lubricate the specified locations after reinstalling GEAR
40T 18T, GEAR 48T, GEAR 60T 18T.
Refer to Section “6.3.2.2 Lublication” (p551).
