Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 644
LIN_DAA_REG16 300 051
---
074
SiDAA country setting register 1 ---
0x04
---
(bit0) Ringer Threshold Select 0 = 11 To 22 VRMS
1 = 17 To 33 VRMS
0
---
(bit1) Ringer Impedance 0 = Maximum ringer impedance
1 = Synthesize ringer impedance
0
---
(bit3, 2) DC Termination Select 00 = Low Voltage Mode
01 = Japan Mode
10 = FCC Mode
11 = CTR21 Mode
10
---
(bit4) IIR Filter Enable 0 = FIR Filter Enable
1 = IIR Filter Enable
0
---
(bit5) AC Termination Select 0 = Select the real impedance
1 = Select the complex impedance
0
---
(bit6) On-Hook Speed 0 = fast
1 = Slow(AustraliaÅASouth Africa)
0
---
(bit7) DC Termination Off
Fixed to 0
0
---
LIN_DAA_REG17 300 052
---
075
SiDAA country setting register 2 ---
0x00
---
(bit0) Billing Tone Detected 0 = No billing tone detected
1 = Billing tone detected
0
---
(bit1) ReceiVe OVerload 0 = Normal receiVe input leVel
1 = ExcessiVe receiVe input leVel
0
---
(bit2) Billing Tone Protect Enable 0 = Billing Tone Protect disabled
1 = Billing Tone Protect enabled
0
---
(bit3) OVerload Protect Enable 0 = Disable oVerload protection
1 = Enable oVerload protection
0
---
(bit4) Current Limit 0 = All other mode
1 = CTR21 moded
0
---
(bit5) Auto-Calibration Disable 0 = Enable auto-calibration
1 = Disable auto-calibration
0
---
(bit6) Manual Calibration 0 = No calibration
1 = Initiate calibration
0
---
(bit7) ReserVed
Fixed to 0
0
---
Table 7-18. List of System Parameter (Phone Line)
Label
Maintenance
Code
User
Access
Internal
Address
Description Setting Value Default Remarks
Main Sub
