Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 646
LIN_ONHOOK_LVCS_BASE 300 055
---
078
SiDAA on-hook detection threshold value (LVCS value) 1 to 30
20
(20)
---
LIN_ONHOOK_LVCS_MIN 300 056
---
079
SiDAA on-hook detection lowest level (LVCS value) 1 to 31 (LVCS value)
7
(7)
---
LIN_ONHOOK_LVCS_CHG 300 057
---
07A
SiDAA on-hook detection variation range (LVCS value) 1 to 31 (LVCS value)
6
(6)
---
LIN_ONHOOK_RATE_NORING 300 058
---
07B
SiDAA ring noiseless on-hook threshold value (%) 1 to 100% (1 step = 1%)
85%
(85)
---
LIN_ONHOOK_RATE_RING 300 059
---
07C
SiDAA ringing on-hook threshold value (%) 1 to 100% (1 step = 1%)
85%
(85)
---
LIN_DIAL_END_TIME 300 060
---
07D
Dialing end judging time 0 to 25.5 sec(1 step = 100 ms)
5.5 seconds
(55)
---
LIN_NUM_DP 300 061
---
07E
Number of pulses of DP
0 = n, "0"=10
1 = "10-n"
2 = "n+1"
n, ”0”=10
(0)
---
LIN_DTMF_TX_TIME 300 062
---
07F
PB (DTMF) transmitting time
Tone transmitting time at PB (DTMF) dialing
0 to 255 ms (1 step = 1 ms)
100 ms
(100)
---
LIN_DTMF_PAUSE_TIME 300 063
---
080
PB (DTMF) pose time
Interdigit time at PB (DTMF) dialing
0 to 255 ms (1 step = 1 ms)
101 ms
(101)
---
LIN_DTMF_TX_LEVEL 300 064
---
081
PB (DTMF) transmitting level
DTMF transmitting attenuator level at PB (DTMF) dialing
4 to 15 (-4 to -15 dBm)
4 = -4 dBm
5 = -5 dBm
6 = -6 dBm
:
15 = -15 dBm
-9 dBm
(9)
---
LIN_DTMF_LEVEL_GAP 300 065
---
082
PB (DTMF) level differenceDifference between the higher and
lower audio frequencies at PB (DTMF) dialing
Difference = Higher frequencies ñ Lower frequencies
0 = 2.0 dB
1 = 2.5 dB
2 = 3.0 dB
3 = 3.5 dB
4 = 4.0 dB
5 = 4.5 dB
6 = 5.0 dB
12 = 0 dB
13 = 0.5 dB
14 = 1.0 dB
15 = 1.5 dB
2.0 dB
(0)
---
Table 7-18. List of System Parameter (Phone Line)
Label
Maintenance
Code
User
Access
Internal
Address
Description Setting Value Default Remarks
Main Sub
