Quidway S6500 Series Ethernet Switches Chapter 2 Qos Command
Huawei Technologies Proprietary
2-5
Fielde Explanation
GigabitEthernet5/0/1: traffic-red
Outbound:
Matches: acl r1 rule 0 running
Queue length of start random
discarding: 64
Queue length of stop random
discarding: 128
Max probability of discarding: 20
RED configuration of the port:
“Outbound” means that this configuration
is effective to packets sent by interfaces.
“ Matches: acl r1 rule 0 running” is the
rule of packet classification.
“ Queue length of start random
discarding: 64” means the queue length
at which the packets will be discarded
randomly; the packet whose length is less
than 64 will not be discarded.
“ Queue length of stop random
discarding: 128” means the queue length
at which the random packet drop will stop;
the packet whose length is larger than
128 will be totally discarded.
“Max probability of discarding: 20”
represents that the probability of
discarding when the queue reaches the
length where the system stops random
discarding.
GigabitEthernet5/0/1:traffic-statistic
Inbound:
Matches: acl std1 rule 0 running
0 byte
0 packet
Outbound:
Matches: acl std1 rule 1 running
0 byte
0 packet
Traffic statistics:
“ Matches: acl std1 rule 0 running 0
byte 0 packet” means that the number
of the packets that match with the subrule
0 of ACL std1 is 0.
“ Matches: acl std1 rule 1 running 0
byte 0 packet” means that the number
of the packets that match with the subrule
1 of ACL std1 is 0.
