Agilent Technologies InfiniiVision 3000 X-Series

104 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:VAMPlitude
[<source>] (see
page 456)
:MEASure:VAMPlitude?
[<source>] (see
page 456)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the amplitude
of the selected waveform in volts
in NR3 format
:MEASure:VAVerage
[<interval>][,][<sour
ce>] (see page 457)
:MEASure:VAVerage?
[<interval>][,][<sour
ce>] (see page 457)
<interval> ::= {CYCLe | DISPlay}
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= calculated
average voltage in NR3 format
:MEASure:VBASe
[<source>] (see
page 458)
:MEASure:VBASe?
[<source>] (see
page 458)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<base_voltage> ::= voltage at the
base of the selected waveform in
NR3 format
:MEASure:VMAX
[<source>] (see
page 459)
:MEASure:VMAX?
[<source>] (see
page 459)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= maximum
voltage of the selected waveform
in NR3 format
:MEASure:VMIN
[<source>] (see
page 460)
:MEASure:VMIN?
[<source>] (see
page 460)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= minimum
voltage of the selected waveform
in NR3 format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
