Agilent Technologies InfiniiVision 3000 X-Series

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 105
:MEASure:VPP
[<source>] (see
page 461)
:MEASure:VPP?
[<source>] (see
page 461)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:VRATio
[<interval>][,][<sour
ce1>] [,<source2>]
(see page 462)
:MEASure:VRATio?
[<interval>][,][<sour
ce1>] [,<source2>]
(see page 462)
<interval> ::= {CYCLe | DISPlay}
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the ratio
value in dB in NR3 format
:MEASure:VRMS
[<interval>][,]
[<type>][,]
[<source>] (see
page 463)
:MEASure:VRMS?
[<interval>][,]
[<type>][,]
[<source>] (see
page 463)
<interval> ::= {CYCLe | DISPlay}
<type> ::= {AC | DC}
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= calculated dc
RMS voltage in NR3 format
n/a :MEASure:VTIMe?
<vtime>[,<source>]
(see page 464)
<vtime> ::= displayed time from
trigger in seconds in NR3 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= voltage at the
specified time in NR3 format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
