4 Commands Quick Reference
:MEASure:VTOP
[<source>] (see
page 465)
:MEASure:VTOP?
[<source>] (see
page 465)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= voltage at the
top of the waveform in NR3 format
:MEASure:WINDow
<type> (see page 466)
:MEASure:WINDow? (see
page 466)
<type> ::= {MAIN | ZOOM | AUTO}
:MEASure:XMAX
[<source>] (see
page 467)
:MEASure:XMAX?
[<source>] (see
page 467)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
:MEASure:XMIN
[<source>] (see
page 468)
:MEASure:XMIN?
[<source>] (see
page 468)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
Table 18 :MTESt Commands Summary
Command Query Options and Query Returns
:MTESt:ALL {{0 | OFF}
| {1 | ON}} (see
page 494)
:MTESt:ALL? (see
page 494)
{0 | 1}
:MTESt:AMASk:CREate
(see page 495)
n/a n/a
:MTESt:AMASk:SOURce
<source> (see
page 496)
:MTESt:AMASk:SOURce?
(see page 496)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:MTESt:AMASk:UNITs
<units> (see
page 497)
:MTESt:AMASk:UNITs?
(see page 497)
<units> ::= {CURRent | DIVisions}
