Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

1046 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
35 Obsolete and Discontinued Commands
Discontinued
Commands
Discontinued commands are commands that were used by previous
oscilloscopes, but are not supported by the InfiniiVision 3000 X- Series
oscilloscopes. Listed below are the Discontinued commands and the
nearest equivalent command available (if any).
:PRINt? (see page 1088):DISPlay:DATA? (see
page 304)
:SAVE:IMAGe:AREA (see
page 1090)
none
:TIMebase:DELay (see
page 1093)
:TIMebase:POSition (see
page 868) or
:TIMebase:WINDow:POSition
(see page 873)
TIMebase:POSition is position
value of main time base;
TIMebase:WINDow:POSition
is position value of zoomed
(delayed) time base window.
:SBUS<n>:LIN:SIGNal:DEFiniti
on (see page 1091)
none
:SBUS<n>:SPI:SOURce:DATA
(see page 1092)
:SBUS<n>:SPI:SOURce:MOSI
(see page 747)
:TRIGger:THReshold (see
page 1094)
:POD<n>:THReshold (see
page 527) or
:DIGital<d>:THReshold (see
page 295)
:TRIGger:TV:TVMode (see
page 1095)
:TRIGger:TV:MODE (see
page 945)
Obsolete Command Current Command Equivalent Behavior Differences
Discontinued Command Current Command Equivalent Comments
ASTore :DISPlay:PERSistence INFinite
(see page 307)
CHANnel:MATH :FUNCtion:OPERation (see
page 347)
ADD not included
CHANnel<n>:PROTect :CHANnel<n>:PROTection
(see page 276)
Previous form of this
command was used to
enable/disable 50Ω
protection. The new command
resets a tripped protect and
the query returns the status of
TRIPed or NORMal.
DISPlay:INVerse none
DISPlay:COLumn none
DISPlay:FREeze none
