4 Commands Quick Reference
:TRIGger:GLITch:LEVel
<level> [<source>]
(see page 911)
:TRIGger:GLITch:LEVel
? (see page 911)
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers (DSO
models), <level> ::= ±(external
range setting) in NR3 format.
For digital channels (MSO
models), <level> ::= ±8 V.
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:TRIGger:GLITch:POLar
ity <polarity> (see
page 912)
:TRIGger:GLITch:POLar
ity? (see page 912)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:GLITch:QUALi
fier <qualifier> (see
page 913)
:TRIGger:GLITch:QUALi
fier? (see page 913)
<qualifier> ::= {GREaterthan |
LESSthan | RANGe}
:TRIGger:GLITch:RANGe
<less_than_time>[suff
ix],
<greater_than_time>[s
uffix] (see page 914)
:TRIGger:GLITch:RANGe
? (see page 914)
<less_than_time> ::= 15 ns to
10 seconds in NR3 format
<greater_than_time> ::= 10 ns to
9.99 seconds in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
:TRIGger:GLITch:SOURc
e <source> (see
page 915)
:TRIGger:GLITch:SOURc
e? (see page 915)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
Table 53 :TRIGger:GLITch Commands Summary (continued)
Command Query Options and Query Returns
