Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

146 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:TRIGger:PATTern:QUAL
ifier <qualifier>
(see page 924)
:TRIGger:PATTern:QUAL
ifier? (see page 924)
<qualifier> ::= {ENTered |
GREaterthan | LESSthan | INRange
| OUTRange | TIMeout}
:TRIGger:PATTern:RANG
e
<less_than_time>[suff
ix],
<greater_than_time>[s
uffix] (see page 926)
:TRIGger:PATTern:RANG
e? (see page 926)
<less_than_time> ::= 15 ns to
10 seconds in NR3 format
<greater_than_time> ::= 10 ns to
9.99 seconds in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
Table 55 :TRIGger:PATTern Commands Summary (continued)
Command Query Options and Query Returns
Table 56 :TRIGger:RUNT Commands Summary
Command Query Options and Query Returns
:TRIGger:RUNT:POLarit
y <polarity> (see
page 928)
:TRIGger:RUNT:POLarit
y? (see page 928)
<polarity> ::= {POSitive |
NEGative | EITHer}
:TRIGger:RUNT:QUALifi
er <qualifier> (see
page 929)
:TRIGger:RUNT:QUALifi
er? (see page 929)
<qualifier> ::= {GREaterthan |
LESSthan | NONE}
:TRIGger:RUNT:SOURce
<source> (see
page 930)
:TRIGger:RUNT:SOURce?
(see page 930)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:RUNT:TIME
<time>[suffix] (see
page 931)
:TRIGger:RUNT:TIME?
(see page 931)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
Table 57 :TRIGger:SHOLd Commands Summary
Command Query Options and Query Returns
:TRIGger:SHOLd:SLOPe
<slope> (see
page 933)
:TRIGger:SHOLd:SLOPe?
(see page 933)
<slope> ::= {NEGative | POSitive}
:TRIGger:SHOLd:SOURce
:CLOCk <source> (see
page 934)
:TRIGger:SHOLd:SOURce
:CLOCk? (see
page 934)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
