Agilent Technologies InfiniiVision 3000 X-Series

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 153
:WGEN:ARBitrary:DATA:
DAC {<binary> |
<value>, <value> ...}
(see page 1003)
n/a <binary> ::= decimal 16-bit
integer values between -512 to
+511 in IEEE 488.2 binary block
format
<value> ::= decimal integer
values between -512 to +511 in
comma-separated NR1 format
:WGEN:ARBitrary:INTer
polate {{0 | OFF} |
{1 | ON}} (see
page 1004)
:WGEN:ARBitrary:INTer
polate? (see
page 1004)
{0 | 1}
:WGEN:ARBitrary:STORe
<source> (see
page 1005)
n/a <source> ::= {CHANnel<n> |
WMEMory<r> | FUNCtion | MATH}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
:WGEN:FREQuency
<frequency> (see
page 1006)
:WGEN:FREQuency? (see
page 1006)
<frequency> ::= frequency in Hz
in NR3 format
:WGEN:FUNCtion
<signal> (see
page 1007)
:WGEN:FUNCtion? (see
page 1009)
<signal> ::= {SINusoid | SQUare |
RAMP | PULSe | NOISe | DC | SINC
| EXPRise | EXPFall | CARDiac |
GAUSsian | ARBitrary}
:WGEN:FUNCtion:PULSe:
WIDTh <width> (see
page 1010)
:WGEN:FUNCtion:PULSe:
WIDTh? (see
page 1010)
<width> ::= pulse width in
seconds in NR3 format
:WGEN:FUNCtion:RAMP:S
YMMetry <percent>
(see page 1011)
:WGEN:FUNCtion:RAMP:S
YMMetry? (see
page 1011)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
:WGEN:FUNCtion:SQUare
:DCYCle <percent>
(see page 1012)
:WGEN:FUNCtion:SQUare
:DCYCle? (see
page 1012)
<percent> ::= duty cycle
percentage from 20% to 80% in NR1
format
:WGEN:MODulation:AM:D
EPTh <percent> (see
page 1013)
:WGEN:MODulation:AM:D
EPTh? (see page 1013)
<percent> ::= AM depth percentage
from 0% to 100% in NR1 format
:WGEN:MODulation:AM:F
REQuency <frequency>
(see page 1014)
:WGEN:MODulation:AM:F
REQuency? (see
page 1014)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
:WGEN:MODulation:FM:D
EViation <frequency>
(see page 1015)
:WGEN:MODulation:FM:D
EViation? (see
page 1015)
<frequency> ::= frequency
deviation in Hz in NR3 format
Table 62 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
