Agilent Technologies InfiniiVision 3000 X-Series

154 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:WGEN:MODulation:FM:F
REQuency <frequency>
(see page 1016)
:WGEN:MODulation:FM:F
REQuency? (see
page 1016)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
:WGEN:MODulation:FSKe
y:FREQuency <percent>
(see page 1017)
:WGEN:MODulation:FSKe
y:FREQuency? (see
page 1017)
<frequency> ::= hop frequency in
Hz in NR3 format
:WGEN:MODulation:FSKe
y:RATE <rate> (see
page 1018)
:WGEN:MODulation:FSKe
y:RATE? (see
page 1018)
<rate> ::= FSK modulation rate in
Hz in NR3 format
:WGEN:MODulation:FUNC
tion <shape> (see
page 1019)
:WGEN:MODulation:FUNC
tion? (see page 1019)
<shape> ::= {SINusoid | SQUare|
RAMP}
:WGEN:MODulation:FUNC
tion:RAMP:SYMMetry
<percent> (see
page 1020)
:WGEN:MODulation:FUNC
tion:RAMP:SYMMetry?
(see page 1020)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
:WGEN:MODulation:NOIS
e <percent> (see
page 1021)
:WGEN:MODulation:NOIS
e? (see page 1021)
<percent> ::= 0 to 100
:WGEN:MODulation:STAT
e {{0 | OFF} | {1 |
ON}} (see page 1022)
:WGEN:MODulation:STAT
e? (see page 1022)
{0 | 1}
:WGEN:MODulation:TYPE
<type> (see
page 1023)
:WGEN:MODulation:TYPE
? (see page 1023)
<type> ::= {AM | FM | FSK}
:WGEN:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 1025)
:WGEN:OUTPut? (see
page 1025)
{0 | 1}
:WGEN:OUTPut:LOAD
<impedance> (see
page 1026)
:WGEN:OUTPut:LOAD?
(see page 1026)
<impedance> ::= {ONEMeg | FIFTy}
:WGEN:PERiod <period>
(see page 1027)
:WGEN:PERiod? (see
page 1027)
<period> ::= period in seconds in
NR3 format
:WGEN:RST (see
page 1028)
n/a n/a
:WGEN:VOLTage
<amplitude> (see
page 1029)
:WGEN:VOLTage? (see
page 1029)
<amplitude> ::= amplitude in
volts in NR3 format
Table 62 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
