Agilent Technologies InfiniiVision 3000 X-Series

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 155
:WGEN:VOLTage:HIGH
<high> (see
page 1030)
:WGEN:VOLTage:HIGH?
(see page 1030)
<high> ::= high-level voltage in
volts, in NR3 format
:WGEN:VOLTage:LOW
<low> (see page 1031)
:WGEN:VOLTage:LOW?
(see page 1031)
<low> ::= low-level voltage in
volts, in NR3 format
:WGEN:VOLTage:OFFSet
<offset> (see
page 1032)
:WGEN:VOLTage:OFFSet?
(see page 1032)
<offset> ::= offset in volts in
NR3 format
Table 62 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
Table 63 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 1035)
n/a <r> ::= 1-2 in NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 1036)
:WMEMory<r>:DISPlay?
(see page 1036)
<r> ::= 1-2 in NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 1037)
:WMEMory<r>:LABel?
(see page 1037)
<r> ::= 1-2 in NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:WMEMory<r>:SAVE
<source> (see
page 1038)
n/a <r> ::= 1-2 in NR1 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1 to (# analog channels)
in NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
:WMEMory<r>:SKEW
<skew> (see
page 1039)
:WMEMory<r>:SKEW?
(see page 1039)
<r> ::= 1-2 in NR1 format
<skew> ::= time in seconds in NR3
format
:WMEMory<r>:YOFFset
<offset>[suffix] (see
page 1040)
:WMEMory<r>:YOFFset?
(see page 1040)
<r> ::= 1-2 in NR1 format
<offset> ::= vertical offset
value in NR3 format
[suffix] ::= {V | mV}
