Agilent Technologies InfiniiVision 3000 X-Series

34 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
:POWer:SIGNals:VMAXimum:ONOFf:ON (see
page 577)
Specifies the maximum expected input voltage
for turn on analysis.
:POWer:SIGNals:VSTeady:ONOFf:OFF (see
page 578)
Specifies the expected steady state output DC
voltage of the power supply for turn off
analysis.
:POWer:SIGNals:VSTeady:ONOFf:ON (see
page 579)
Specifies the expected steady state output DC
voltage of the power supply for turn on
analysis.
:POWer:SIGNals:VSTeady:TRANsient (see
page 580)
Specifies the expected steady state output DC
voltage of the power supply for transient
response analysis.
:WGEN:MODulation:AM:DEPTh (see
page 1013)
Specifies the amount of amplitude modulation.
:WGEN:MODulation:AM:FREQuency (see
page 1014)
Specifies the frequency of the modulating
signal.
:WGEN:MODulation:FM:DEViation (see
page 1015)
Specifies the frequency deviation from the
original carrier signal frequency.
:WGEN:MODulation:FM:FREQuency (see
page 1016)
Specifies the frequency of the modulating
signal.
:WGEN:MODulation:FSKey:FREQuency (see
page 1017)
Specifies the "hop frequency".
:WGEN:MODulation:FSKey:RATE (see
page 1018)
Specifies the rate at which the output
frequency "shifts".
:WGEN:MODulation:FUNCtion (see page 1019) Specifies the shape of the modulating signal.
:WGEN:MODulation:FUNCtion:RAMP:SYMMet
ry (see page 1020)
Specifies the amount of time per cycle that the
ramp waveform is rising.
:WGEN:MODulation:STATe (see page 1022) Enables or disables modulated waveform
generator output.
:WGEN:MODulation:TYPE (see page 1023) Selects the modulation type: Amplitude
Modulation (AM), Frequency Modulation (FM),
or Frequency-Shift Keying Modulation (FSK).
Command Description
Command Differences
:BLANk (see page 198) You can now use the WMEMory<r> source parameter to turn
off the display of a reference waveform location.
