ETC Cobalt 10 - Facepanel - Cobalt LS

Cobalt 8.1 - 20181029
1002
Facepanel - Cobalt LS
The Cobalt Light Server’s 19”-design packs the identical features, channel and output counts as the
Cobalt console into a stand-alone, rack-mountable enclosure suitable for permanently installed
applications. Running Cobalt’s operating software, the Cobalt Light Server is a fully independent
lighting playback controller or a convenient back-up option. There are twenty keys with a shift
function in the front panel that make it possible to run a lot of functions. An external mouse is
supplied and recommended.
Button functions - unshifted
1 2 3 4 5 6 7 8 9 0
Ch Thru All + @ Output Master Point C Shift
Button functions - shifted
Esc Up Modify Insert Live Format Tab Browser Macro Load
Play
Left Down Right Delete Goto GO Pause Go Back Record Shift
We recommend the use of X-keys. See X-keys.
