Templates - Mode Tables
ModeTables make it possible to control multiple mode devices such as, for example, the High End
x.Spot™.
• A set of ranges are defined for a parameter.
• The Table defines which range is used for one parameter based upon the Range setting of
another parameter.
In the High End x.Spot™ there are Mode parameters (color mode) that affect the function of another
parameter (color wheel). When a mode is set by selecting a Range on one function, the corresponding
Table Range will be assigned to the other parameter.
If there are both Range Tables and Ranges defined for a parameter, the Range Table will be used if
there is a corresponding range, otherwise the normal Ranges will be used.
Define A Mode Range Table
1. Define the ranges for the different "modes" of the Device. See Device Templates - Ranges.
2. Define Range Tables for these modes in the corresponding function parameter. Start by opening the
Range Table editor by pressing MODIFY in the Tables
column of the Template Editor.
This is the Template Mode Range Table editor for Gobo in a High End x.Spot™ Color parameter.
