Cobalt 8.1 - 20181029
282
Channel List - Columns & Functions
Column Input Function
Channel No input The number of this Channel - cannot be
edited here (see Output List).
Dimmer Address #.# Enter the address, followed by decimal point
and then DMX universe. You can change
the universe by entering ".#"
Dimmer Address
[MODIFY]
Opens an Output Editor for adding multiple
outputs or editing.
Device No input Shows the device template - cannot be
edited here (see Device Settings).
Device Address #.# Enter the address, followed by decimal point
and then DMX universe. You can change
the universe by entering ".#"
(see Device Settings).
Scale 0-200% Sets the scaling factor for the intensity of
this channel.
Park 0-100% Shows the level a channel is parked at. Set a
level with # MODIFY and remove with C &
MODIFY. See Park.
Name 0-6144 Enter the number and press MODIFY to
change a channel name (see Renaming
Channels).
