Template Range Editor - Columns
Function Value Feedback
Min 0-255 This is the start value for a sub range*. The same
value for Min and Max will be treated like a position
(for a color or gobo for example). The Min value can
be entered in the Min% column as well.
Max 0-255 This is the end value for a sub range*. The Max
value can be entered in the Max% column as well.
Min% 0-100 The Min value can be entered as % here instead of
bits (0-255) in Min.
Max% 0-100 The Max value can be entered as % here instead of
bits (0-255) in Max.
Text
This text is displayed in all editors, and in with the
Parameter Wheels.
Centered On/Off When On, selecting a range will set the output to the
middle of the given range. Parameter values are
displayed relative to this centre position with +/-
steps.
This can useful for speed, rotation or index
parameters for wheels, with a stop position in the
middle.
*Values between positions (start=stop) cannot be set with the wheel, unless they are specified as
subranges.
Template Range Wizard
Press WIZARD in the Template Range Editor. This Wizard simplifies entering a number of evenly
spread ranges, for example frames, between 0-255. This is useful to create positions for a scroller, or a
gobo/color wheel.
1. Open the Template Range Editor. See Device Template - Ranges
.
2. Press WIZARD.
