Device Control - Fan
The FAN key in the programming section is used to distribute values of a parameter evenly around a
centre point.
There are four shapes of fan:
Linear
S = S shaped
V = V shaped
U = U shaped
Function Key Feedback
1. Select channels Channel Select
functions
Selected channels are
highlighted in the Channel
View
2. Select base channel*
[NEXT]
The focused channel is
highlighted in red
3. Fan parameter #
[FAN] & [Wheel]
Parameter # is fanned
according to the shape in
the Settings, around the
channel focused by
NEXT/LAST.
*If no base channel is selected, the centre channel of the selection is used.
