Connectors
These are the connectors in the back of the console.
This chapter contains the following sections
• Connector - DMX512
• Connector - DVI/sVGA Monitor
• Connector - Phone remote
• Connector - MIDI
• Connector - External Trig 1-9
• Connector - Ethernet
• Connector - Keyboard, Printer & Mouse
• Connector - Desk Light
Connector - DMX512
There are two DMX512A/RDM ports
Pin 1 Gnd
Pin 2 Data-
Pin 3 Data+
Connector - DVI/sVGA Monitor
These connectors support DVI/sVGA external displays (1280x1024 minimum resolution) with
optional single or multi-touch screen control.
