Main Playback - Refresh Functions
The REFRESH key in the Main Playback can be used to refresh any part of a channel to the resulting
state of the current Sequence Step in the Main Playback.
Function Key
Everything
[REFRESH]
Attributes of all device(s)
[REFRESH] & [ATTRIB]
Levels of all device(s) and channel(s)
[REFRESH] & [@LEVEL]
Focus parameters of the selected device(s)
[REFRESH] & [FOCUS]
Color parameters of the selected device(s)
[REFRESH] & [COLOR]
Beam parameters of the selected device(s)
[REFRESH] & [BEAM]
Wheel parameters of the selected device(s)
[REFRESH] & [Wheel_key]
U1-U3 of the selected device(s)
[REFRESH] & [U1
U3]
Intensities AND attributes for the
selected device(s).
[REFRESH] & [CHANNEL]
NOTE
The changed flags are cleared for what you refresh.
The Refresh function will take the currently focused channel into account if
you are using NEXT/LAST.
