4 Commands Quick Reference
Table 51 :TRIGger:EBURst Commands Summary
Command Query Options and Query Returns
:TRIGger:EBURst:COUNt
<count> (see
page 897)
:TRIGger:EBURst:COUNt
? (see page 897)
<count> ::= integer in NR1 format
:TRIGger:EBURst:IDLE
<time_value> (see
page 898)
:TRIGger:EBURst:IDLE?
(see page 898)
<time_value> ::= time in seconds
in NR3 format
:TRIGger:EBURst:SLOPe
<slope> (see
page 899)
:TRIGger:EBURst:SLOPe
? (see page 899)
<slope> ::= {NEGative | POSitive}
:TRIGger:EBURst:SOURc
e <source> (see
page 900)
:TRIGger:EBURst:SOURc
e? (see page 900)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
Table 52 :TRIGger[:EDGE] Commands Summary
Command Query Options and Query Returns
:TRIGger[:EDGE]:COUPl
ing {AC | DC |
LFReject} (see
page 902)
:TRIGger[:EDGE]:COUPl
ing? (see page 902)
{AC | DC | LFReject}
:TRIGger[:EDGE]:LEVel
<level> [,<source>]
(see page 903)
:TRIGger[:EDGE]:LEVel
? [<source>] (see
page 903)
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers, <level>
::= ±(external range setting) in
NR3 format.
For digital channels (MSO
models), <level> ::= ±8 V.
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal } for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
