H3C S3600 Series User Manual

Operation Manual – Management VLAN
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Management VLAN Configuration
1-3
Operation Command Description
Shut down the
management VLAN
interface
shutdown
Bring up the
management VLAN
interface
undo shutdown
Optional
By default, a management VLAN
interface is down if all the
Ethernet ports in the
management VLAN are down; a
management VLAN interface is
up if one or more Ethernet ports in
the management VLAN are up.
Caution:
z To configure the management VLAN of a switch operating as a cluster management
device to be a cluster management VLAN (using the management-vlan vlan-id
command) successfully, make sure the vlan-id argument provided in the
management-vlan vlan-id command is consistent with that of the management
VLAN.
z Bringing up or shutting down a management VLAN interface has no effect on the
up/down status of the Ethernet ports in the management VLAN.
1.2.3 Configuration Example
I. Network requirements
To manage the switch SwitchA remotely through Telnet, These requirements are to be
met: SwitchA has an IP address, and the route between SwitchA and the remote
console is reachable.
You need to configure the switch as follows:
z Assigning an IP address to the management VLAN interface
z Configuring the default route
II. Configuration procedure
# Enter system view.
<H3C> system-view
# Create VLAN 10 and configure VLAN 10 to be the management VLAN.
[H3C] vlan 10
[H3C-vlan10] quit
[H3C] management-vlan 10
# Create the VLAN 10 interface and enter VLAN interface view.
[H3C] interface vlan-interface 10
