H3C S3600 Series User Manual

Operation Manual – Login
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 8
User Control
8-9
II. Network diagram
Internet
Sw itc h
Internet
Sw itc h
s Figure 8-3 Network diagram for controlling Web users using ACL
III. Configuration procedure
# Define a basic ACL.
<H3C> system-view
[H3C] acl number 2030 match-order config
[H3C-acl-basic-2030] rule 1 permit source 10.110.100.46 0
[H3C-acl-basic-2030] rule 2 deny source any
# Apply the ACL to only permit the Web users sourced from the IP address of
10.110.100.46 to access the switch.
[H3C] ip http acl 2030
