Operation Manual – Routing Protocol
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 3
RIP Configuration
3-12
IV. Setting RIP-2 packet authentication mode
RIP-2 supports two authentication modes: simple authentication and MD5
authentication.
Simple authentication cannot provide complete security, because the authentication
keys sent along with packets that are not encrypted. Therefore, simple authentication
cannot be applied where high security is required.
Table 3-15 Set RIP-2 packet authentication mode
Operation Command Description
Enter system
view
system-view
Enter interface
view
interface interface-type
interface-number
Set RIP-2 packet
authentication
mode
rip
authentication-mode
{ simple password |
md5 { rfc2453 key-string
| rfc2082 key-string
key-id } }
Required
If you specify to use MD5
authentication, you must specify
one of the following MD5
authentication types:
rfc2453 (this type supports the
packet format defined in RFC 2453)
rfc2082 (this type supports the
packet format defined in RFC 2082)
V. Configuring a RIP neighbor
Table 3-16 Configure a RIP neighbor
Operation Command Description
Enter system view
system-view
Enter RIP view
rip
Configure a RIP
neighbor
peer ip-address
Required
To make RIP to work on a link that does
not support broadcast/multicast packets,
you must manually configure the RIP
neighbor.
Normally, RIP uses broadcast or
multicast addresses to send packets.
