H3C S3600 Series User Manual

Operation Manual – Login
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2 Logging in through the Console Port
2-4
Table 2-2 Common configuration of Console port login
Configuration Remarks
Baud rate
Optional
The default baud rate is 9,600 bps.
Check mode
Optional
By default, the check mode of the Console
port is set to “none”, which means no check
bit.
Stop bits
Optional
The default stop bits of a Console port is 1.
Console port
configuration
Data bits
Optional
The default data bits of a Console port is 8.
AUX user
interface
configuration
Configure the
command level
available to the users
logging into the AUX
user interface
Optional
By default, commands of level 3 are
available to the users logging into the AUX
user interface.
Make terminal
services available
Optional
By default, terminal services are available in
all user interfaces
Set the maximum
number of lines the
screen can contain
Optional
By default, the screen can contain up to 24
lines.
Set history command
buffer size
Optional
By default, the history command buffer can
contain up to 10 commands.
Terminal
configuration
Set the timeout time
of a user interface
Optional
The default timeout time is 10 minutes.
Caution:
Changing of Console port configuration terminates the connection to the Console port.
To establish the connection again, you need to modify the configuration of the
termination emulation utility running on your PC accordingly. Refer to section
2.2
“Logging in through the Console Port” for more.
2.3.2 Console Port Login Configurations for Different Authentication Modes
Table 2-3 lists Console port login configurations for different authentication modes.
