H3C S3600 Series User Manual

Operation Manual – Mirroring
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Mirroring Configuration
1-11
Operation Command Description
Configure a remote
reflector port
mirroring-group group-id
reflector-port
reflector-port
Required
The remote reflector port
must be of the Access
type. LACP and STP must
be disabled on this port.
After a port is configured
as a reflector port, the
switch does not allow you
to perform any of the
following configurations:
z Changing the port type
or its default VLAN ID
z Add the port to another
VLAN
Configure the
remote-probe VLAN for
the remote source
mirroring group
mirroring-group group-id
remote-probe vlan
remote-probe-vlan-id
Required
Display the configuration
of the remote source
mirroring group
display mirroring-group
remote-source
Optional
This command can be
executed in any view.
 Note:
z The reflector port cannot forward traffics as a normal port. In this scenario, it is
recommended that you use an idle and down port as the reflector port, and do not
perform other configuration on this port.
z If the mac-address max-mac-count 0 command is executed on a port in a VLAN, it
is recommended not to configure this VLAN as the remote-probe VLAN. Otherwise,
remote mirroring may not work properly.
z Do not configure a port connecting the intermediate switch or destination switch as
the mirroring source port. Otherwise, traffic disorder may occur in the network.
III. Configuring RSPAN on the intermediate switch
Table 1-10 Configure RSPAN on the intermediate switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and enter
VLAN view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN to
be defined.
