H3C S3600 Series User Manual

Operation Manual – Multicast
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 6 IGMP Configuration
6-5
z On VLAN-interface2, configure VLAN-interface1 as the outbound IGMP Proxy
interface to external networks. You must enable the IGMP protocol on the interface
first, and then configure the igmp proxy command.
Configure Switch A as follows:
z Enable multicast routing and configure the IGMP protocol on VLAN-interface1.
z Configure the pim neighbor-policy command to filter PIM neighbors in the
network segment 33.33.33.0/24. That is, Switch A does not consider Switch B as
its PIM neighbor.
In this case, when Switch B of leaf network receives from VLAN-interface2 an IGMP
join or IGMP leave message sent by the host, it will change the source address of the
IGMP information to the address of VLAN-interface1: 33.33.33.2 and send the
information to VLAN-interface1 of Switch A. For Switch A, this works as if there is a host
directly connected to VLAN-interface1.
Similarly, when Switch B receives the IGMP general group or group-specific query
message from the Layer 3 Switch A, it will also change the source address of the query
message to the IP address of VLAN-interface2: 22.22.22.1 and send the message from
VLAN-interface2.
In
Figure 6-2, VLAN-interface2 of Switch B is called the client and VLAN-interface1 of
Switch B is called the proxy.
6.2 IGMP Configuration
You cannot perform other IGMP configuration tasks until you enable the IGMP protocol
after multicast is enabled.
IGMP configuration tasks include:
Table 6-1 Configuration task overview
Operation Description Related section
Configure IGMP version Optional
Section
6.2.1 "Configuring IGMP
Version"
Configure IGMP query
packets
Optional
Section 6.2.2 "Configuring IGMP
Query Packets"
Configure IGMP multicast
groups on the interface
Optional
Section 6.2.3 “Configuring IGMP
Multicast Groups on the Interface"
Configure router ports to
join the specified
multicast group
Optional
Section 6.2.4 "Configuring Router
Ports to Join the Specified
Multicast Group"
Configure IGMP Proxy Optional
Section
6.2.5 "Configuring IGMP
Proxy"
