Operation Manual – Login
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2 Logging in through the Console Port
2-11
2.5.2 Configuration Example
I. Network requirements
Assume the switch is configured to allow you to login through Telnet, and your user
level is set to the administrator level (level 3). After you telnet to the switch, you need to
limit the console user at the following aspects.
z Authenticate users logging in through the Console port using the local password.
z Set the local password to 123456 (in plain text).
z The commands of level 2 are available to users logging into the AUX user
interface.
z The baud rate of the Console port is 19,200 bps.
z The screen can contain up to 30 lines.
z The history command buffer can store up to 20 commands.
z The timeout time of the AUX user interface is 6 minutes.
II. Network diagram
User PC running Telnet
Ethernet1/0/1
Et he r net
User PC running Telnet
Ethernet1/0/1
Et he r net
Figure 2-6 Network diagram for AUX user interface configuration (with the
authentication mode being
password)
III. Configuration procedure
# Enter system view.
<H3C> system-view
# Enter AUX user interface view.
[H3C] user-interface aux 0
# Specify to authenticate users logging in through the Console port using the local
password.
[H3C-ui-aux0] authentication-mode password
# Set the local password to 123456 (in plain text).
