H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1 Port Basic Configuration
1-5
1.2.2 Limiting Traffic on individual Ports
By performing the following configurations, you can limit different types of incoming
traffic on individual ports. When a type of incoming traffic exceeds the threshold you set,
the system drops the packets exceeding the traffic limit to reduce the traffic ratio of this
type to the reasonable range, so as to keep normal network service.
Table 1-4 Limit traffic on port
Operation Command Remarks
Enter system view
system-view
—
Limit broadcast traffic
received on each port
broadcast-suppression
{ ratio | pps max-pps }
Optional
By default, the switch
does not suppress
broadcast traffic.
Enter Ethernet port view
interface interface-type
interface-number
—
Limit broadcast traffic
received on the current
port
broadcast-suppression
{ ratio | pps max-pps }
Optional
By default, the switch
does not suppress
broadcast traffic.
Limit multicast traffic
received on the current
port
multicast-suppression
{ ratio | pps max-pps }
Optional
By default, the switch
does not suppress
multicast traffic.
Limit unknown unicast
traffic received on the
current port
unicast-suppression
{ ratio | pps max-pps }
Optional
By default, the switch
does not suppress
unknown unicast traffic.
1.2.3 Enabling Flow Control on a Port
Flow control is enabled on both the local and peer switches. If congestion occurs on the
local switch:
z The local switch sends a message to notify the peer switch of stopping sending
packets to itself or reducing the sending rate temporarily.
z The peer switch will stop sending packets to the local switch or reduce the sending
rate temporarily when it receives the message; and vice versa. By this way, packet
loss is avoided and the network service operates normally.
