Operation Manual – Cluster

H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1

Cluste

1-20

 Note:

z After completing the above configuration, you can execute the cluster switch-to

{ member-number | mac-address H-H-H } command on the management device to

switch to member device view to maintain and manage a member device. After that,

you can execute the cluster switch-to administrator command to return to

management device view.

z In addition, you can execute the reboot member { member-number | mac-address

H-H-H } [ eraseflash ] command on the management device to reboot a member

device. For detailed information about these operations, refer to the preceding

description in this chapter.

z After the above configuration, you can receive logs and SNMP trap messages of all

cluster members on the NMS.

1.6.2 NM Interface Configuration Example

I. Network requirements

z Configure VLAN-interface 2 as the NM interface of the switch;

z Configure VLAN 3 as the management VLAN;

z The IP address of the FTP server is 192.168.4.3;

z The S3600 switch is the management switch;

z The S3526E and S2403 switches are member switches.

Table 1-19 Connection information of the management switch

VLAN IP address Connection port

VLAN 3 (connect to S3526E) 192.168.5.30/24 Ethernet 1/0/1

VLAN 2 (connect to FTP server) 192.168.4.22/24 Ethernet 1/0/2
