H3C S3600 Series User Manual

Operation Manual – Mirroring
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Mirroring Configuration
1-5
z The destination port is determined.
z The port to be configured with traffic mirroring function and the direction of the
traffic flow to be mirrored are determined.
II. Configuration procedure
Table 1-4 Configure traffic mirroring
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port view
of the determined
destination port
interface interface-type
interface-number
—
Define the current port as
the destination port
monitor-port
Required
LACP and STP must be
disabled on the
destination port.
Exit current view
quit
—
Enter Ethernet port view
of traffic mirroring
configuration
interface interface-type
interface-number
—
Invoke ACLs for
identifying traffic flows
and perform traffic
mirroring for the packets
matching the ACLs.
mirrored-to { inbound |
outbound } acl-rule
{ monitor-interface |
cpu }
Required
Display the parameter
settings of traffic mirroring
display qos-interface
{ interface-type
interface-number |
unit-id } mirrored-to
Display all QoS settings of
a port
display qos-interface
{ interface-type
interface-number |
unit-id } all
Optional
These commands can be
executed in any view.
acl-rule: applied ACL rules, which can be the combination of different types of ACL
sub-rules. The following table describes the combined-ACL applications.
Table 1-5 Combined-ACL applications
Combination mode Form of acl-rule
Apply all sub-rules in an IP type ACL (either a
basic or an advanced ACL) separately
ip-group acl-number
Apply one sub-rule in an IP type ACL
separately
ip-group acl-number rule rule-id
