H3C S3600 Series User Manual

Operation Manual – SNMP-RMON
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
SNMP Configuration
1-7
1.3.2 Configuration Tasks
Table 1-4 Configure Trap
Operation Command Description
Enter system view
system-view
—
Enable the device to
send Trap packets
snmp-agent trap enable
[ configuration | flash | ospf
[ process-id ] [ ospf-trap-list ] |
standard [ authentication |
coldstart | linkdown | linkup |
warmstart ]* | system | vrrp
[ authfailure | newmaster ] ]
Enter port
view or
interface view
interface interface-type
interface-number
Enable the
port or
interface to
send Trap
packets
enable snmp trap updown
Enable
the port
to send
Trap
packets
Quit to
system view
quit
Optional
By default, a
port is enabled
to send all
types of Traps.
Set the destination for
Trap packets
snmp-agent target-host trap
address udp-domain { ip-address }
[ udp-port port-number ] params
securityname security-string [ v1 |
v2c | v3 {authentication | privacy } ]
Required
Set the source address
for Trap packets
snmp-agent trap source
interface-type interface-number
Optional
Set the size of the queue
used to hold the Traps to
be sent to the destination
host
snmp-agent trap queue-size size
Optional
The default is
100.
Set the aging time for
Trap packets
snmp-agent trap life seconds
Optional
The default
Trap packet
aging time is
120 seconds.
