H3C S3600 Series User Manual

Operation Manual – Login
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2 Logging in through the Console Port
2-12
[H3C-ui-aux0] set authentication password simple 123456
# Specify commands of level 2 are available to users logging into the AUX user
interface.
[H3C-ui-aux0] user privilege level 2
# Set the baud rate of the Console port to 19,200 bps.
[H3C-ui-aux0] speed 19200
# Set the maximum number of lines the screen can contain to 30.
[H3C-ui-aux0] screen-length 30
# Set the maximum number of commands the history command buffer can store to 20.
[H3C-ui-aux0] history-command max-size 20
# Set the timeout time of the AUX user interface to 6 minutes.
[H3C-ui-aux0] idle-timeout 6
2.6 Console Port Login Configuration with Authentication
Mode Being Scheme
2.6.1 Configuration Procedure
Table 2-8 Console port login configuration with the authentication mode being scheme
Operation Command Description
Enter system view
system-view
—
Enter the
default ISP
domain
view
domain domain-name
Specify the
AAA
scheme to
be applied
to the
main
do
scheme { local | none
| radius-scheme
radius-scheme-name
[ local ] |
hwtacacs-scheme
hwtacacs-scheme-na
me [ local ] }
Configur
e the
authentic
ation
mode
Quit to
system
view
quit
Optional
By default, the local AAA
scheme is applied.
If you specify to apply the local
AAA scheme, you need to
perform the configuration
concerning local user as well.
If you specify to apply an
existing scheme by providing
the radius-scheme-name
argument, you need to perform
the following configuration as
well:
z Perform AAA-RADIUS
configuration on the switch.
(Refer to the
AAA-RADIUS-HWTACACS-
EAD module for more.)
z Configure the user name and
password accordingly on the
AAA server. (Refer to the
user manual of AAA server.)
